DIN 41612 Female straight, type M Part No. 124-40162-00
Illustration similar
Perpendicular
Through Hole
Power
Rugged
- Termination length 4.6 mm
- 42 + 6 contacts
- solder
- performance level 2
Technical Specifications
Basics
Specification | IEC 60603-2 (DIN 41612) |
---|---|
Performance Level | 2 |
No. of Contacts | 42 + 6 |
Termination Technology | solder |
Termination Length | 4.6 mm |
Operating Temperature Range | -55°C to +125°C |
Material
Insulator Material | PBT glass filled UL 94 V-0 |
---|---|
CTI value IEC 60112 | 200 |
Contact Material | Copper alloy |
Mechanical
Pitch | 2.54 mm |
---|---|
Mating Force | < 40 N |
Separating Force per Pin | > 0.15 N |
Durability | 400 mating cycles |
Electrical
Operational Current | 4.8 A |
---|---|
Contact Resistance | <20 mΩ |
Clearance and Creepage | ≥ 1.2 mm |
Insulation Resistance | >106 MΩ |
Test Voltage | 1000 V |
Processing
Soldering Temperature | to 260°C |
---|
Approval / Compliance
UL file | E130314 |
---|---|
Environment | RoHS compliant |
Dimensions
For details please download the drawings or contact ept directly.
Options
Board Lock
Suitable for connectors with type B, C, D, E, F low profile, G low profile, M female connectors and R male connectors | ||||||
Forces | Part Number | PCB Thickness | ||||
Type of Insertion | Fm | not soldered Fh | soldered Fh | 124-40162-00C1 | 1.6 mm | |
Locked | < 20 N | > 10 N | > 25 N | 124-40162-00C2 | 2.4 mm | |
Under Tension | < 20 N | > 5 N | > 25 N | 124-40162-00C3 | 3.6 mm |
Matching Products
DIN 41612 Male 90°, type M
Part Number 123-40161-00
Modifications
Available on request
- Without flange
- Special contact length
- Performance levels I + III or customer-specific
- Contact arrangement
Packaging
Tube
25 pcs / Tube
12 Tube / Box
