backDescriptionTechnical SpecificationsDerating DiagramOptionsModificationsPackagingDownloadsStock Check
DIN 41612 Male 90°, type H15 Part No. 113-40060
Illustration similar
Perpendicular
Through Hole
Power
Rugged
- Termination length 3 mm
- 15 contacts
- premating contact at pos. Z32
- solder
- performance level 2
Technical Specifications
Basics
Specification | IEC 60603-2 (DIN 41612) |
---|---|
Performance Level | 2 |
No. of Contacts | 15 |
Termination Technology | solder |
Termination Length | 3 mm |
Operating Temperature Range | -55°C to +125°C |
Material
Insulator Material | PBT glass filled UL 94 V-0 |
---|---|
CTI value IEC 60112 | 200 |
Contact Material | Copper alloy |
Mechanical
Pitch | 5.08 x 6.0 mm |
---|---|
Mating Force | < 90 N |
Separating Force per Pin | > 0.2 N |
Durability | 400 mating cycles |
Electrical
Operational Current | 15 A |
---|---|
Contact Resistance | <8 mΩ |
Clearance and Creepage | cr: ≥ 8.0 mm, cl: ≥ 4.5 mm |
Insulation Resistance | >106 MΩ |
Test Voltage | 3100 V |
Processing
Soldering Temperature | to 260°C |
---|
Approval / Compliance
UL file | E130314 |
---|---|
Environment | RoHS compliant |
Options
Board Lock 90°
Suitable for connectors with type B, C, D, E, F, G male connectors and R female connectors | ||||||
Type of Insertion | Forces | PCB Thickness | Part Number | |||
Fm | not soldered Fh | soldered Fh | 113-40060C1 | |||
Locked | < 30 N | > 10 N | > 20 N | ≤ 1.6 mm | ||
Under Tension | < 30 N | > 7.5 N | > 20 N | > 1.6 mm |
Modifications
Available on request
- Pre-mating and late-mating contacts
- Contact arrangement
Packaging
Box
19 pcs / Box
14 Box / Box
